DESCRIPTION

Basic Info.

Model NO.	LM-TR781600-001R-T1
Range of Application	Choke
Packaging Form	Epoxy Resin Inductance
Brand	Ikp
Inductor Value	Variable Inductor
Transport Package	CTN
Specification	0.4mH 80A
Trademark	IKP
Origin	China
HS Code	8504319000
Production Capacity	5000pieces/Day

Product Description

Features:
1. Organic silicone potting, soft material, good shock absorption and protection effect
2. The physical and chemical properties are stable, high temperature and low temperature resistance, can work in the range of -50 ~ 200 degrees
3. Excellent electrical performance and insulation ability, long service life
4. The soft potting compound is easy to take out, and the components can be repaired or replaced quickly
Product Details:
Brand: IKP
P.N: LM781600-001R
Core: Sendust core*5
Inductance: 0.4mH
Rated current: 80A
Copper wire: Φ1.5mm*14
Winding: 1 start, 2 finish
Insulation system: Class B 130°C
Storage temperature: -40°C ~80°C
Operation temperature: -40°C ~130°C
OCL: pins(1-2)=0.4mH±10% @1kHz, 0.1v
DCR: pins(1-2)=15.0mΩ MAX
Hipot: WDG to CASE 1.5kVac 60Hz 60Seconds 3mA MAX, No flashover
Layer insulation: 1.0kWac no flashover
Electrical and mechanical specifications 100% tested
RoHS compliant compatible
Application:
Solar inverter, Wind inverter, PFC filter, Choke coils, EV inverter, ABS system for car, car generators, inverter air conditioners, etc.
